CERIAN 10W COB LED Strip – 6500K IP67, 10m Roll, 24V DC
The CERIAN IP67 10W COB Flexi LED strip provides smooth, continuous-looking illumination with high-density chip-on-board LEDs. Supplied in a 10-metre roll, this 6500K version is suited to cool-white architectural features, display lighting and contemporary installations, subject to appropriate installation and environmental protection.
Key Features and Technical Specifications
- Brand: CERIAN
- LED type: COB (chip on board)
- Power: 10W per metre
- Operating voltage: 24V DC constant voltage
- Roll length: 10 metres
- Colour temperature: 6500K
- Ingress protection: IP67
- Beam angle: 140°
- Colour rendering: CRI >90
- Construction: Flexible LED strip with protective silicone material
- Mounting: Compatible aluminium profile required for heat management
- Luminous surface width: 4.0 ± 0.2mm
Where to Use 6500K IP67 COB LED Strip Lighting
Use this strip to create even linear lighting for cool-white architectural features, display lighting and contemporary installations. Its high-density COB design helps minimise visible LED dots. The suitability of a particular location depends on the complete installation, including connectors, cut ends, drivers and any exposure to water.
IP67 Water-Resistance Guidance
IP67 protection is dust-tight and rated for temporary immersion under specified test conditions. This does not automatically make it suitable for permanent underwater installation. Cut ends and joints must be sealed to maintain the required protection, using manufacturer-approved methods. Keep LED drivers and connections appropriately protected and follow the manufacturer’s installation instructions.
Installation and Power Planning
- Plan the strip length and check the manufacturer’s cutting marks and maximum supported run length.
- Choose a compatible 24V DC LED driver with suitable power capacity; at 10W/m, a full 10m roll has a nominal strip load of 100W, before any design allowance.
- Install in a suitable aluminium profile for thermal management, and confirm any waterproofing and sealing requirements.
- Peel adhesive backing gradually where fitted; avoid pressing on the emitting surface.
- Check voltage drop and power-feed requirements for longer runs. Have mains connections installed by a licensed electrician.
